Description

1, Glassfiber Texturized yarn
Item: HY-G350T

Description:It is produced by texturizing process with high pressure air. The products have high strength , able to bear high temperature , corrosion resistant , such advantages as insulating ability is good and fire resistant, used for keeping, the insulating material warm, insulating against heat, can make other products . It with metallic can extensively apply to friction materials. It is the excellent substitute for asbestos. Texturized glass fiber yarn with metallic (copper wire, nickel wire or stainless wire) are also available.
E/C-Glassfiber Texturized yarn

Spec: 200tex~4800tex, 20kgs/CTN
Filament size: 6, 8, 9,11 to 13,17μm

2, Glassfiber Roving
Item: HY-G350R

Description:It is the most basic type in the material of glass fiber reinforced plastic (FRP), have good insulation and heat resistance. Mainly used in FRP, for making glassfiber roving cloth, texturized yarn and chopping reinforcement.
E/C-Glassfiber Roving

Spec:
E/C-550,1100,1200,1500,1750,2200,2400tex
20kgs/CTN
Filament size: 6, 9, 11 to 13μm

3, Graphited Glassfiber Rope
Item: HY-G360G

Description:Rround Braided from texturized glass fiber yarn treated with graphite. It is used for the material of keeping warm, insulating against heat etc. It is the excellent substitute for asbestos. For sealing coke furnace, stove and boiler burner, chimney door, pump and valve, exchanger.
Graphited Glassfiber Round rope

Temp.: 550C
Specs.: 5.0mm~50mm
Packing: In CTN or plastic woven bag of 20kg net each

size net weight per coil Length per coil (approx.)
inch mm kg m
1/4 6.4 5 181.5
5/16 8 5 120
3/8 9.6 5 77.5
1/2 12.7 10 89.5
5/8 16 10 70
3/4 19.2 10 44
7/8 22.4 10 33.5
1 25.4 10 28
1-1/8 28.6 10 22.5
1-1/4 32 10 18
1-1/2 38.1 10 12
1-3/4 44.5 10 9.5
2 50.8 10 6.5

4, Glassfiber Tape
Item: HY-G370

Description:Braided with the E/C-fibergalss, had good insulation and heat resistance, extensively apply to building , waterproof , antiseptic and wrapping up the coil of electrical machinery and electrical apparatus. It is an excellent substitute for asbestos tape. It can be with self-adhesive on one side. Dyed or metallic wire reinforced are also available.
Texturized Glassfiber Tape

Temp.: 550C
Thickness:0.8mm~5.0mm
Width:20mm~300mm
Packing:
25m or 30m/roll
In CTN or plastic woven bag of 20kg net each

5, Glass Fiber Cloth
Item: HY-G375

Description: Made of non texturized glassfiber yarns, these cloths appear smooth and have higher weight than the texturized glassfiber cloth. They can be produced by different kinds of weaving---plain, twill, satin. They are widely used in thermal insulation and can be treated in different ways in order to meet specific purposes. Normal for heat shields, removable insulation covers, fire curtains, expansion joints.
Glass fiber Cloth


Style No. Also called Thickness (mm) Weight (g/m2) Weight (oz/y2) Width (m) Weave
GF1020 7628 0.2 205 6.0 1.27 Plain
GF1041 3732 (332) 0.4 430 12.7 1.0-1.8 Satin
GF1050 PW500 0.5 500 14.8 1.0-1.8 Plain
GF1081 3784 0.8 880 26.0 1.0-1.5 Satin
GF1100 PW1000 1.0 1000 29.6 1.0-1.5 Plain
GF1130 3786 1.3 1300 38.5 1.0-1.5 Satin
GF1170 3788 1.7 1700 50.3 1.0-1.5 Satin
Temp.: 550C

6, Glassfiber Welding Blanket
Item: HY-G378B

Description:Our welding blanket is made of fiberglass fabric. It is an ideal replacement for asbestos product used for thermal insulation and heat protection. It will not burn, rot, mildew or deteriorate and resist most acids. Welding blankets are designed to help protect employees from welding hazards. From safety blankets to protect equipment and personnel near welding operations, to hand and sleeve protectors to protect your employees while welding, can help improve the safety of your welding operation.
Glassfiber Welding Blanket

Product Image

  • Glass Fiber Yarn  image
